  • The Science Behind Regenerative Airflow: Why It Matters

    The Science Behind Regenerative Airflow: Why It Matters

    Regenerative airflow plays a vital role in industrial systems that require efficient, continuous, and oil-free air movement. Understanding how it works—and why it matters—can help facilities optimize performance, reduce energy use, and improve reliability.

    What Is Regenerative Airflow?



    Regenerative airflow is a principle used in regenerative blowers (also known as side channel blowers or vortex blowers). These devices generate airflow through a non-positive displacement method using a high-speed impeller and side channels to build and recirculate pressure.

    How It Works: The Science

    1. Air enters the blower housing through the inlet port.
    2. A multi-blade impeller rotating at high speed traps the air between the blades and the side channel.
    3. As the impeller spins, the air follows a spiraling path—accelerated multiple times within the side channel.
    4. This regenerative action adds energy to the air during each pass, increasing both pressure and velocity before discharge.



    Unlike rotary vane or piston compressors, regenerative blowers:

    • Don’t compress air in a single stroke
    • Use continuous acceleration over multiple impeller passes
    • Are designed for high flow, low pressure/vacuum applications

    💡

    Why Regenerative Airflow Matters



    1. Oil-Free Operation
    • Clean, dry air with no risk of oil contamination
    • Essential for food, pharma, and environmental applications



    1. Low Maintenance
    • Fewer moving parts
    • No internal contact = less wear and longer service life



    1. Continuous, Pulsation-Free Flow
    • Stable performance ideal for aeration, vacuum lifting, or pneumatic conveying



    1. Energy Efficiency
    • Efficient in low-pressure and low-vacuum scenarios
    • Optional VFD control for precise flow management



    1. Versatility
    • Suitable for both pressure and vacuum tasks in a wide range of industries

    Common Applications

    • Wastewater aeration
    • Vacuum lifting and packaging
    • Industrial air knives
    • Medical suction systems
    • Pneumatic conveying of powders and pellets
    • Environmental air sampling

    Key Takeaway



    Regenerative airflow delivers efficient, clean, and continuous air movement without the complexity or contamination risks of traditional compressors. For many industrial applications, this makes regenerative blowers a smart, sustainable choice that supports reliability, compliance, and cost control.



  • How does a UPS system help reduce my carbon footprint?

    How does a UPS system help reduce my carbon footprint?

    A UPS (Uninterruptible Power Supply) system can help reduce your carbon footprint by improving the efficiency and sustainability of your power usage—especially when integrated into a broader energy strategy. While traditionally viewed as a backup solution, modern UPS systems actively contribute to energy conservation and emissions reduction in several key ways:

    1. Energy Efficiency Reduces Waste
    • Modern UPS systems—especially those using double conversion or eco-mode—can achieve efficiency ratings of 95%–98%.
    • Less energy is lost as heat, which reduces your electricity usage and cooling requirements in data centers or industrial environments.
    • Lower energy consumption = fewer CO₂ emissions from power generation.
    1. Supports Renewable Energy Integration
    • Advanced UPS systems can interface with solar PV or wind systems to store and manage renewable energy.
    • This reduces dependency on fossil-fuel-based grid power and supports a cleaner energy mix.
    1. Enables Load Shifting and Demand Response
    • Some UPS systems are capable of energy storage and peak shaving, discharging stored energy during peak demand times.
    • This helps reduce strain on the grid and avoids using carbon-intensive peaker plants.
    • When connected to demand response programs, your UPS can support grid stability while earning incentives.
    1. Battery Technology Advancements
    • UPS systems with lithium-ion batteries have longer lifespans and higher energy densities than traditional lead-acid batteries.
    • Fewer replacements and better recyclability reduce the environmental impact over the system’s lifecycle.
    1. Optimized Facility Performance
    • A UPS ensures uninterrupted operation of efficient, digitally controlled equipment (like HVAC and lighting), preventing energy-wasting disruptions or unsafe shutdowns.
    • It also protects sensitive systems, minimizing damage and the need for carbon-intensive equipment replacement.

    Summary: Carbon-Reduction Benefits of a UPS

    Feature

    Carbon Impact

    High Efficiency

    Lowers electricity consumption

    Renewable Integration

    Reduces reliance on fossil fuels

    Load Management

    Supports grid and avoids peak carbon output

    Longer Battery Life

    Minimizes waste and manufacturing emissions

    System Protection

    Reduces downtime and equipment turnover

    Bottom line:

    A UPS isn’t just about power continuity—it can be a strategic tool for sustainability, helping your facility operate more efficiently, reduce energy-related emissions, and support the clean energy transition.

  • What is a Time Current Curve?

    What is a Time Current Curve?

    A time-current curve (TCC) for circuit breakers is a graphical representation that shows how long a circuit breaker will take to trip at various levels of overcurrent. It illustrates the relationship between fault current magnitude and tripping time, helping engineers design protection systems that are both safe and selective.

    What the Time-Current Curve Shows

    • X-axis: Current (as a multiple of the breaker’s rated current, In)
    • Y-axis: Time to trip (typically on a logarithmic scale, in seconds or milliseconds)

     Key Curve Regions

    1. Long-Time Region (Overload Protection)
      • Protects against modest overcurrents (e.g., 1.2–6× In)
      • Trip times range from seconds to minutes
      • Allows temporary inrush currents (like motor starts) without nuisance tripping
    2. Short-Time Region
      • Handles higher overcurrents (e.g., 6–10× In)
      • Trips in tens to hundreds of milliseconds
      • May include adjustable delay for coordination with downstream devices
    3. Instantaneous Region (Short-Circuit Protection)
      • Responds to very high fault currents (e.g., 10× or more)
      • Trips almost immediately—within a few milliseconds

    Why Time-Current Curves Matter

    • Selectivity/Coordination: Ensure only the breaker closest to the fault trips, preventing wider outages.
    • System Protection: Match breaker performance to equipment thermal and mechanical limits.
    • Safety and Compliance: Validate system design against NEC, IEC, or UL standards.

    Example

    A 100A circuit breaker might have a TCC like this:

    Current

    Trip Time

    120A (1.2×)

    20 seconds

    300A (3×)

    2 seconds

    1,000A (10×)

    < 0.1 seconds

    Summary

    A time-current curve is an essential tool for:

    • Sizing breakers
    • Protecting equipment
    • Coordinating multiple protection devices
    • Ensuring system reliability and safety
  • Understanding Flowmeter Accuracy, Repeatability, and Rangeability

    Understanding Flowmeter Accuracy, Repeatability, and Rangeability

    Definition:

    Accuracy is the degree to which the flowmeter’s reading matches the actual flow rate. It is usually expressed as a percentage of:

    • Reading (RD) – more precise at higher flow rates.
    • Full Scale (FS) – used for simpler systems; less accurate at low flows.
    • Span – the difference between maximum and minimum measurable flows.

    Example:

    If a flowmeter has an accuracy of ±1% of reading, and the actual flow is 100 GPM, the meter will read between 99 and 101 GPM.

    Note: Accuracy may vary depending on fluid type, temperature, and installation conditions.

    Flowmeter Repeatability

    Definition:

    Repeatability measures the meter’s ability to provide consistent readings under the same conditions over multiple tests. It is typically tighter than accuracy (e.g., ±0.1% vs. ±1%).

    Why It Matters:

    High repeatability ensures reliable trend data and process control—even if the meter isn’t perfectly accurate.

    Example:

    If a flowmeter shows 100.2, 100.3, and 100.1 GPM under identical conditions, it has good repeatability.

    Flowmeter Rangeability (Turndown Ratio)

    Definition:

    Rangeability is the ratio between the maximum and minimum flow rates that a meter can accurately measure.

    Formula:

    Rangeability = Maximum Flow / Minimum Measurable Flow

    Example:

    A flowmeter with a rangeability of 100:1 can measure from 1 GPM to 100 GPM with reliable accuracy.

    Importance:

    Wide rangeability is critical in applications with variable flow, such as batch processes or systems with seasonal load changes.

    Summary Table

    Parameter Definition Typical Value Importance
    Accuracy Closeness to true flow value ±0.1–2% of reading Ensures flow measurement meets spec
    Repeatability Consistency of readings at same conditions ±0.05–0.2% Essential for reliable trend analysis
    Rangeability Effective measurement range 10:1 to 1000:1 Allows accurate readings over wide flows



  • When do you need a Windows-based HMI?

    When do you need a Windows-based HMI?

    A Windows-based Human-Machine Interface (HMI) is typically used when your application requires advanced functionality, greater flexibility, or integration beyond what embedded or basic HMIs can offer.



    Here’s a guide to help you determine when a Windows-based HMI is the right choice:

    When You Need a Windows-Based HMI



    1. Complex Visualization or SCADA Integration

    • High-resolution graphics, real-time trends, dynamic objects
    • Interactive dashboards, data overlays, alarms, and event logs
    • Integration with full SCADA systems (e.g., Wonderware, Ignition, FactoryTalk View SE)



    2. Extensive Data Handling or Analytics

    • Local or remote SQL/database logging
    • Data trending, historical playback, reporting tools
    • Edge computing capabilities (data pre-processing before sending to cloud)



    3. Multi-Protocol or Enterprise Connectivity

    • Communicates with multiple PLC brands, fieldbuses, or IIoT platforms
    • Connects to MES/ERP systems, cloud storage, OPC UA, MQTT, or REST APIs
    • Often required for Industry 4.0 or smart factory applications



    4. Third-Party Software Integration

    • Need to run other Windows applications alongside HMI software
    • Use of Excel, custom diagnostic tools, vision systems, barcode readers, etc.
    • Ideal when you want to consolidate multiple functions on one terminal



    5. Local Storage & File Management

    • Store and retrieve large volumes of recipes, documents, images, or logs
    • Export data to USB, FTP, or local drives
    • Supports Windows file system navigation



    6. Multi-User Access and Advanced Security

    • Supports user-based logins with different permissions
    • Windows-based domain or Active Directory integration
    • Often used in validated environments (e.g., FDA 21 CFR Part 11 compliance)



    7. Large Screens or Multi-Monitor Setups

    • Touchscreen monitors >15” or multi-screen layouts
    • Visualization of multiple systems or processes in parallel
    • Useful for control rooms, water/wastewater plants, or large industrial lines

    When You May Not Need One



    Stick with an embedded HMI if:

    • You only need basic monitoring and control (start/stop, setpoints)
    • There’s limited space, no PC maintenance allowed, or cost is a constraint
    • You’re working with simple standalone systems or small machines

    Common Industries Using Windows-Based HMIs

    • Water & wastewater treatment plants
    • Food & beverage (with traceability/logging needs)
    • Pharmaceuticals (compliance-driven logging and access control)
    • Automotive and heavy manufacturing (robotic line control)
    • Oil & gas (remote SCADA and process monitoring)
  • Understanding Short Circuit Withstand Time (SCWT) in IGBTs

    Understanding Short Circuit Withstand Time (SCWT) in IGBTs

    Short Circuit Withstand Time (SCWT) is a critical performance parameter in Insulated Gate Bipolar Transistors (IGBTs), especially in high-power applications where short circuit events can occur due to system faults or switching transients.

    What is SCWT?

    SCWT refers to the maximum duration an IGBT can safely tolerate a short circuit condition without being permanently damaged. During a short circuit, the collector-emitter voltage remains high while the current spikes to very high levels. This causes extreme power dissipation within the IGBT, leading to rapid heating.

    Typical SCWT values for modern IGBT modules range from 5 to 10 microseconds (µs), depending on the design and the thermal/electrical robustness of the device.

    Why SCWT Matters

    1. System Protection

    A higher SCWT allows the protection circuitry (like desaturation detection or overcurrent protection) more time to react and shut down the device safely.

    1. Device Reliability

    Devices with better SCWT are less prone to failure during fault events, improving the overall system reliability.

    1. Design Flexibility

    A longer SCWT provides more headroom in gate driver design, reducing the risk of premature failures in demanding environments.

    Factors Influencing SCWT

    • Chip Design & Materials: Advanced trench-gate or field-stop structures and materials (e.g., SiC) can improve SCWT.
    • Gate Resistance and Gate Drive Circuitry: A properly tuned gate drive helps control the short-circuit current profile.
    • Thermal Management: Efficient heat dissipation can delay thermal runaway during fault events.
    • DC Link Inductance: High parasitic inductance can worsen fault conditions, reducing effective SCWT.

    Practical Considerations

    • Always consult the IGBT datasheet to know the specified SCWT under defined test conditions.
    • Ensure protection mechanisms (like soft shutdown or active clamping) can respond faster than the SCWT.
    • For applications prone to frequent or severe short circuits (e.g., motor drives, traction), select IGBTs with robust SCWT ratings.

    Conclusion

    SCWT is not just a design metric; it’s a lifeline for your power electronics system. Choosing an IGBT with adequate SCWT and pairing it with fast, intelligent protection circuitry ensures long-term reliability and safety in high-power environments.

  • Fuji HPnC: High-Power IGBT Modules for Industrial-scale Applications

    Fuji HPnC: High-Power IGBT Modules for Industrial-scale Applications

    Fuji Electric has developed high-performance IGBT (Insulated Gate Bipolar Transistor) modules to meet the need for smaller, efficient, and reliable high-power solutions in industrial, transport, and renewable applications. The High-Power Next Core (HPnC) modules set a new benchmark in power density, efficiency, and ease of use, allowing users to design compact, lightweight, and cost-effective power conversion systems.

    This whitepaper explores key features and benefits of Fuji Electric’s HPnC 7th generation IGBT modules, highlighting improved packaging technology, electrical characteristics, and enhanced reliability. It also compares Fuji’s HPnC with typical high-power modules (HPMs), demonstrating how Fuji’s innovative approach offers performance advantages over competing solutions.

    The Evolution of High-Power IGBT Modules

    High-power IGBT modules, like the standard High Power Modules (HPM), have been a common solution for power conversion systems requiring high current or voltage ratings. These modules, housed in large packages, e.g., the 130mm x 140mm and 140mm x 190mm, have been widely used in industries like renewable energy, traction, and industrial drives. However, as the power electronics industry has advanced, the limitations of HPM have become apparent. The bulk and weight of these modules impact the overall system footprint and add complexity to the design process. Moreover, the overlap in the circuit layer of HPMs makes paralleling multiple modules challenging, typically requiring intricate bus bar designs and consideration of stray inductances.

    Through extensive research and development efforts, Fuji has introduced several generations of high-power modules while improving power density, electrical performance, and reliability. 7th-gen HPnC modules are a major milestone in this journey. By utilizing advanced packaging and optimized chip technology, Fuji has reduced module size and weight while improving the electrical characteristics and simplifying the paralleling process.

    7th-Gen IGBT Modules: A Closer Look at Fuji Electric’s HPnC

    Fuji offers a broad range of HPnC module options to cater to diverse application requirements, with Silicon (Si) and Silicon Carbide (SiC) variants within the HPnC family. The Si-based HPnC modules are a cost-effective solution for applications that demand high efficiency, reliability, and power density. To meet the growing demand for even higher performance and efficiency, users can opt for SiC variants. SiC MOSFETs exhibit lower on-resistance and faster switching speeds than Si IGBTs, allowing users to design power conversion systems with ultra-low losses and high power density.

    Compactness & Optimized Construction

    One of the main benefits of Fuji’s HPnC modules is their reduced sizes and weight compared to standard HPMs. With a compact 99.5mm x 144mm package, this footprint reduction makes it easier to design space-efficient power conversion systems. Furthermore, they have a weight reduction of approximately 27% compared to HPMs. The lower weight can reduce overall system cost, as lighter modules require less robust mounting structures.

    In addition to a compact and lightweight design, HPnC modules benefit from a simplified and optimized internal layout. A frequent challenge with using HPMs is paralleling modules and the need for complex bus bar designs due to the overlap of circuit layers. In contrast, Fuji HPnC modules adopt a straightforward approach by positioning the AC terminal layer opposite the collector and emitter circuit layer. This layout optimization simplifies the paralleling process and enables easy connection of modules without needing intricate bus bar designs. Moreover, the simplified layout reduces stray inductances, enables faster switching speeds, and improves overall performance.

    Advanced Chip Technology

    7th-Gen HPnC modules utilize Fuji’s latest X-Series chip technology, an advanced IGBT/FWD (free wheeling diode) chipset that offers several benefits over previous generations. Firstly, the X-Series IGBTs feature a lower collector-emitter saturation voltage (Vce(sat)) than their predecessors. This reduction in on-state voltage drop reduces conduction losses, resulting in higher efficiency and low heat generation. Moreover, X-Series IGBTs exhibit a lower surge voltage during turn-off due to an optimized chip design and improved controllability. The decreased voltage helps minimize electrical stress on the IGBT and associated components, enhancing the overall reliability and robustness of the power module. Additionally, the X-Series FWDs incorporated in the HPnC modules are designed to have soft-reverse recovery characteristics. By lowering the peak reverse recovery current and its associated losses, this feature improves overall efficiency and reduces electromagnetic interference (EMI) in power conversion systems.

    Robust Internal Construction & Low Internal Inductance

    Reliability and robustness are essential factors in high-power applications, and Fuji has emphasized enhancing these aspects in their HPnC modules. One key element contributing to improved reliability is using a new high-performance insulating material, an insulating resin with a Comparative Tracking Index (CTI) greater than 600. This high-CTI resin provides excellent electrical insulation properties and reduces the risk of insulation breakdown in harsh environmental conditions.

    HPnC modules utilize materials optimized to withstand extreme thermal cycling conditions. By incorporating ultrasonic-welded terminals and a choice of a MgSiC (Magnesium Silicon Carbide) or Cu (Copper) baseplate, the HPnC modules can endure many thermal cycles without compromising their structural integrity. For example, HPnC modules with a Cu baseplate can withstand up to 5,000 cycles at a temperature difference (ΔTc) of 80K in industrial applications.

    In traction applications, where the thermal stress is even more demanding, HPnC modules with a MgSiC baseplate can endure up to 12,500 cycles at a ΔTc of 90K. This thermal cycling capability ensures long-term reliability and reduces the risk of premature module failure. With an inductance of just 12.5 nH, approximately 70% lower than a typical HPM, HPnC modules also minimize the impact of stray inductances. Moreover, their low inductance design allows the modules to achieve faster switching speeds, reduces overshoot voltages, and minimizes the risk of electrical noise and EMI issues.

    Comparative Analysis: HPnC vs. High-Power Modules

    This section presents a comparative analysis of HPnC modules concerning standard High Power Modules (HPM), Infineon’s PrimePACK™ modules, and the Mega Power Dual modules.

    For package sizing, HPnC modules offer a more compact footprint of 99.5mm x 144mm, which is significantly smaller than the typical 130mm x 140mm and 140mm x 190mm packages used in typical HPMs. While the PrimePACK™ modules have a slightly smaller package size of 89mm x 250mm, the HPnC modules balance compactness and power density. The Mega Power Dual modules have a package size of approximately 130mm x 150mm.

    Another benefit of HPnC modules is their weight reduction. Compared to conventional HPMs, HPnC modules are approximately 27% lighter. This weight reduction contributes to simplified mechanical design, reduced system-level costs, and improved power density. The lighter weight of HPnC modules allows for compact heatsinks and mounting structures, contributing to space savings and cost reduction in power conversion systems.

    Thermal cycling capability is a critical factor in high-power applications, as it directly impacts the long-term reliability and lifetime of the power modules. HPnC modules exhibit superior thermal cycling performance, surpassing the other modules. When equipped with a Cu-baseplate, HPnC modules can withstand up to 5,000 cycles at a temperature difference (ΔTc) of 80K due to a high CTI > 600. In comparison, HPM and PrimePACK™ modules have a CTI > 400, withstanding 3,000 cycles at the same ΔTc, while Mega Power Dual modules endure up to 4,000 cycles.

    Key Applications

    Fuji’s HPnC modules are designed to cater to a broad range of applications, offering customers the flexibility to utilize them in various industries. Key applications include traction inverter, UPS, industrial drive systems, and renewable energy installations.

    In traction inverter applications, like those found in locomotives, EVs, and off-highway vehicles, HPnC modules offer high performance and reliability. The modules’ high power density and low-loss design of efficient, compact traction inverters help reduce the overall system size and weight. Moreover, the high thermal cycling capability of HPnC modules equipped with a MgSiC baseplate ensures long-term operation and minimizes the risk of costly downtime.

    Renewable energy systems, including solar power conditioning systems (PCS) and wind turbine converters, can also benefit from Fuji’s HPnC modules. The small footprint and low inductances of HPnC modules allow you to design high-power, high-efficiency inverters and converters for renewable energy applications. The simplified paralleling capability of HPnC modules is particularly advantageous in large-scale solar and wind installations, where multiple modules are often required to achieve the desired power ratings. By reducing the complexity of system design and installation, HPnC modules can speed up deployment times and lower costs in renewable energy projects.

    Uninterruptible power supplies (UPS) are another key application where HPnC modules can be applied. The lower losses and high thermal cycling capability can improve UPS efficiency and reliability. The compact size of HPnC modules also enables the design of more space-efficient UPS, which is crucial in data centers and industrial environments where floor space is at a premium.

    In industrial drive applications, such as manufacturing, material handling, and HVAC systems, Fuji HPnC modules offer a combination of high efficiency, reliability, and performance. Their low losses and fast switching capabilities allow users to design more efficient and responsive drive systems. The high reliability and thermal cycling of HPnC modules with a Cu baseplate ensures long-term operation and reduced maintenance requirements in industrial environments.

    Conclusion

    With their compact sizes, low inductance, improved electrical characteristics, and high reliability, Fuji Electric’s 7th-Gen HPnC modules allow you to design more efficient, space-saving, and cost-effective power conversion systems. These products offer customers the flexibility to scale their power solutions to meet the demands of various industrial-scale applications.

    For more information on Fuji Electric’s 7th-Gen HPnC modules or application-specific inquiries, please visit the website or contact Fuji Electric’s sales team.

  • What characteristics should we look at when searching for an SiC module?

    What characteristics should we look at when searching for an SiC module?

    Silicon Carbide (SiC) modules are known for their superior performance in power electronics applications due to the material’s unique properties. When searching for an SiC module for your specific application,, several key characteristics should be considered.

    Here are important factors to evaluate:

    1. Voltage and Current Ratings:
      • Maximum Collector-Emitter Voltage (Vce): Indicates the maximum voltage the module can handle. Choose a SiC module with a voltage rating higher than the maximum voltage in your application.
      • Collector Current (Ic): Specifies the maximum current the module can carry. Select a module with a current rating that exceeds the maximum current requirements of your application.
    2. Module Configuration:
      • Topology: SiC modules come in various configurations, such as half-bridge, full-bridge, or three-phase bridge. Select the module type that fits your application’s power topology.
    3. Switching Speed:
      • Turn-On and Turn-Off Speeds: SiC devices have faster switching speeds compared to traditional silicon devices. Ensure that the SiC module’s switching speeds align with the requirements of your application.
    4. On-State Resistance (Rdson):
      • Low Rdson: SiC modules exhibit low on-state resistance, which contributes to reduced conduction losses. Choose a SiC module with an Rdson value suitable for your application to ensure efficient power handling.
    5. Gate Drive Requirements:
      • Gate Voltage (Vge): Specifies the voltage required to drive the gate of the SiC module. Ensure compatibility with the gate drive circuitry in your application.
      • Gate Charge (Qg): The total electric charge required to switch the SiC module. Understanding gate charge is crucial for selecting an appropriate gate driver.
    6. Thermal Performance:
      • Thermal Resistance (Rth): Indicates how effectively the SiC module can dissipate heat. Lower thermal resistance is generally preferable for better thermal performance. Adequate thermal management is crucial for the reliability and longevity of the module.
    7. Module Construction and Packaging:
      • Package Type: Consider the physical form factor of the SiC module, such as module dimensions and mounting options. Common package types include module housing, press-pack modules, or other specialized packages.
    8. Body Diode Characteristics:
      • Body Diode Reverse Recovery Time: If the SiC module has an integrated body diode, consider its reverse recovery time. Fast reverse recovery times are essential in certain applications to minimize losses.
    9. Operating Temperature Range:
      • Consider the range of temperatures in which the SiC module is designed to operate. Ensure that it aligns with the environmental conditions of your application.
    10. Protection Features:
      • Look for additional protection features such as short-circuit protection, overcurrent protection, and temperature monitoring. These features enhance the module’s reliability and protect it from potential faults.
    11. Reliability and MTBF (Mean Time Between Failures):
      • Evaluate the reliability specifications of the SiC module, and consider the Mean Time Between Failures (MTBF) for an indication of expected operational reliability.
    12. Application-Specific Considerations:
      • Consider any specific requirements or features needed for your application, such as regenerative braking capability, fast-switching capabilities, or specialized protection features.
    13. Manufacturer Reputation and Support:
      • Choose SiC modules from reputable manufacturers known for producing high-quality, reliable components. Consider the availability of technical support, documentation, and application notes.

    It’s important to carefully evaluate these characteristics and compare them with the requirements of your application. This will help you can select a SiC module that provides optimal performance, reliability, and efficiency in your application.

  • How do SiC devices work?

    How do SiC devices work?

    Silicon Carbide (SiC) devices are a type of wide-bandgap semiconductor technology that has gained attention for its superior performance compared to traditional silicon-based devices. SiC is a compound of silicon and carbon and is known for its excellent material properties, allowing the development of high-performance electronic devices.

    Here’s a general overview of how SiC devices work:

    1. Material Properties:
      • Wide Bandgap: One of the key advantages of SiC is its wide bandgap, which is significantly larger than that of silicon. This wide bandgap allows SiC devices to operate at higher temperatures, voltages, and frequencies without suffering from the same level of performance degradation as silicon-based devices.
    2. Types of SiC Devices:
      • SiC MOSFETs (Metal-Oxide-Semiconductor Field-Effect Transistors): These are voltage-controlled devices that use the same principles as silicon MOSFETs but leverage the superior material properties of SiC for higher efficiency and faster switching speeds.
      • SiC Schottky Diodes: SiC diodes exploit the material’s characteristics to provide fast switching, low forward voltage drop, and high-temperature operation.
    3. SiC MOSFET Operation:
      • Gate Control: SiC MOSFETs operate by applying a voltage to the gate terminal, creating an electric field that controls the flow of charge carriers (electrons or holes) between the source and drain terminals.
      • Wide Bandgap Benefits: The wide bandgap allows SiC MOSFETs to handle higher electric fields, resulting in better performance at high voltages. Additionally, SiC MOSFETs exhibit lower on-state resistance (Rdson) and faster switching speeds compared to traditional silicon MOSFETs.
    4. SiC Schottky Diode Operation:
      • Rectification: SiC Schottky diodes are used for rectification in power electronic circuits. They have a metal-semiconductor junction, and the absence of a P-N junction reduces forward voltage drop and switching losses.
      • Fast Switching: The absence of a reverse recovery charge in SiC Schottky diodes leads to fast switching speeds, reducing switching losses.
    5. Applications:
      • Power Electronics: SiC devices are commonly used in power electronic applications, such as power converters, inverters, and motor drives. Their high-temperature tolerance, efficiency, and fast switching speeds make them suitable for these applications.
      • Electric Vehicles (EVs): SiC devices contribute to the efficiency and performance of electric vehicle powertrains by enabling higher switching frequencies and reducing losses.
    6. Advantages:
      • Higher Temperature Operation: SiC devices can operate at higher temperatures than traditional silicon devices.
      • Higher Efficiency: The superior material properties of SiC contribute to lower conduction and switching losses, leading to higher overall efficiency in power electronic systems.
      • Reduced Size and Weight: SiC devices allow for the design of smaller and lighter power electronic systems due to their improved performance.

    While SiC devices offer numerous advantages, their adoption is influenced by factors such as cost and manufacturing challenges. As technology advances, ongoing research and development aim to address these challenges, making SiC technology even more competitive in various applications.

  • Everything you need to know about conversions of pressure units

    Everything you need to know about conversions of pressure units

    The commonly used units of pressure are the pascal (Pa), the standard atmosphere (atm), the bar, the millimeter of mercury (mmHg) and the psi. The pascal is the international and legal unit of pressure, corresponding to 1 newton per square meter (1 Pa = 1 N/m²). Other pressure units are converted from the pascal. For example, 1 bar equals 100,000 Pa and 1 atm equals 101,325 Pa. There are also other pressure units, such as millimeters of mercury, centimeters of water and psi, which are used in specific fields. Knowing the equivalence between these units makes it easy to convert pressure from one unit to another.

    Pressure is a fundamental physical quantity used to measure the force exerted on a given surface. It plays a crucial role in various fields such as meteorology, industry and physics. Understanding what is a pressure transmitter, the units of pressure and how to convert them is essential for correctly interpreting pressure measurements and assessments. Pressure is defined as the quotient of a force (F) over the area of the surface (S) to which it is applied: p = F/S. There are different units of pressure used around the world, each with its own specific field of application and equivalences.

    Commonly used pressure units

    • The standard atmosphere (atm): The standard atmosphere is a unit of pressure used to measure atmospheric pressure. One standard atmosphere is equivalent to the pressure exerted by a 760 mm column of mercury at 0°C. 1 atm = 101,325 Pa.
    • The bar: The bar is a unit of pressure commonly used to measure the pressure of tyres, oxygen and acetylene cylinders, as well as in scuba diving applications. One bar is approximately equal to atmospheric pressure. 1 bar = 100,000 Pa.
    • The millimeter of mercury (mmHg): The millimeter of mercury, also known as the torr, is a unit of pressure historically used in physics. 760 mmHg corresponds to one atmosphere at 0°C. 1 mmHg = 133.322368 Pa at 0°C.
    • The psi (pound per square inch): The psi is a unit of pressure widely used to measure tyre pressure. 1 psi is equivalent to approximately 6894.76 Pa.
